Passware Kit Mobile requires the device to be in BROM (Boot ROM) mode to start the user data extraction process.
The images below show the test points for different Kirin-based Huawei smartphones. Visit iFixit for instructions on disassembling mobile devices.
If you have photos of other test points, please share them with us.
Brand: Platform:
(version 8, 9, 10)
HiSilicon KIRIN 990 5G
- P40 (Models: ANA-AN00, ANA-TN00, ANA-NX9, ANA-LX4; Release: March 2020)
- P40 Pro (Models: ELS-NX9, ELS-N04, ELS-AN00, ELS-TN00; Release: March 2020)
- Mate 30 Pro 5G (Models: LIO-N29, LIO-AL10, LIO-TL10; Release: September 2019)
HiSilicon KIRIN 990
HiSilicon KIRIN 985 5G
HiSilicon KIRIN 980
- Mate 20 (Models: HMA-L29, HMA-L09, HMA-LX9, HMA-AL00, HMA-TL00; Release: Oct 2018)
- Mate 20 Pro (Models: LYA-L09, LYA-L29, LYA-AL00, LYA-AL10, LYA-TL00, LYA-L0C; Release: Oct 2018)
- P30 Pro (Models: VOG-L29, VOG-L09, VOG-AL00, VOG-TL00, VOG-L04, VOG-AL10, HW-02L; Release: Mar 2019)
- Nova 5T (Models: YAL-L21, YAL-L61, YAL-L71, YAL-L61D; Release: Aug 2019)
-
P30 (Models: ELE-AL00 / ELE-TL00 / ELE-AL10 / ELE-L29; Release: Mar 2019)
NOTE: For P30 you might need to add a 10k resistor between the red and green wires.
HiSilicon KIRIN 970
- Mate 10 Pro (Models: BLA-L29, BLA-L09, BLA-AL00, BLA-A09; Release: Oct 2017)
- P20 (Models: EML-L29C, EML-L09C, EML-AL00 EML-TL00, EML-L29, EML-L09, EML-AL00, EML-TL00; Release: Mar 2018)
- P20 Pro (Models: CLT-L29C, CLT-L29, CLT-L09C, CLT-L09, CLT-AL00, CLT-AL01, CLT-TL01, CLT-AL00L, CLT-L04, HW-01K, CLT-L0J; Release: Mar 2018)
HiSilicon KIRIN 960
- P10 (Models: VTR-L29, VTR-AL00, VTR-TL00, VTR-L09; Release: Feb 2017
- P10 Plus (Models: VKY-L29, VKY-L09, VKY-AL00; Release: Feb 2017)
- Mate 9 Pro (Models: LON-L29, LON-AL00; Release: Jan 2017
HiSilicon KIRIN 810
HiSilicon KIRIN 710F
HiSilicon KIRIN 710
- P30 lite (Models: MAR-LX1M, MAR-AL00, MAR-TL00, MAR-LX2, Marie-L21A, Marie-L01A, Marie-L21MEA, Marie-L22A, MAR-LX1A, MAR-LX3A, MAR-LX2J, MAR-LX1B, MAR-LX3Bm; Release: Mar 2019)
- Mate 20 lite (Models: SNE-AL00, SNE-LX1, SNE-LX2, SNE-LX3, INE-LX2; Release: Aug 2018)
- Nova 3i (Models: INE-LX1, INE-LX1r, INE-LX1, Sydney 6353, INE-LX2r, INE-AL00, INE-TL00; Release: July 2018)
HiSilicon KIRIN 659
- P20 lite (Models: NE-TL00, ANE-LX1, ANE-LX2, ANE-LX3, ANE-LX2J, ANE-AL00, ANE-L23, ANE-L22, ANE-L21, HWV32, ANE-TL00; Release: Mar 2018)
- P smart (Models: FIG-LX1, FIG-LA1, FIG-LX2, FIG-LX3, FIG-TL10, FIG-AL10; Release: Dec 2017)
- Y9 - 2018 (Models: RAM: FLA-AL10, FLA-AL00, FLA-LX1, FLA-LX2, FLA-LX3, LDN-AL00, FLA-AL20, FLA-TL10; Release: Mar 2018)
- Mate 10 Lite (Models: RNE-L21, RNE-L22, RNE-L01, RNE-L02, RNE-L11, RNE-L23, RNE-L03, RNE-AL00; Release: Oct 2017)
- Nova 2 (Models: PIC-AL00, PIC-TL00, PIC-LX9, HWV31; Release: May 2017)
- Nova 2 plus (Models: BAC-AL00, BAC-L03, BAC-L23, BAC-L21, BAC-L22; Release: May 2017)
__________________________________________________
Resources:
https://romgoc.net/testpoint-huawei-p40-pro-unbrickfrp/
https://forum.gsmhosting.com/vbb/f492/need-mate-20-test-point-2598716/
https://www.tembelpanci.com/2019/06/huawei-mate-20-pro-test-point.html
https://forum.gsmhosting.com/vbb/f929/huawei-p30-pro-vog-l29-test-point-need-2822179/
https://www.facebook.com/fettafuang/photos/testpoint-huawei-mate-10-alp/1186480788200230/
https://www.nicagsm.com/reparar-imei-huawei-eml-l09/
https://www.tembelpanci.com/2019/06/huawei-p20-pro-eml-l29-test-point.html
https://easy-firmware.com/index.php?a=articles&b=article&id=234
https://forum.gsmhosting.com/vbb/f1022/huawei-test-point-gallery-2291781/#post12802055
https://romprovider.com/test-point-unbrick-huawei-p20-lite/
https://www.mobilerdx.com/2019/09/huawei-p-smart-test-point-remove-frp-lock-using-mrt-dongle.html
https://www.mobilerdx.com/2019/11/huawei-y9-2018-test-point-for-remove-pattern-frp-and-flashing.html
https://www.martview-forum.com/threads/all-huawei-latest-model-testpoint-hisilicon-huawei-usb-com-1-0.14966/
https://androidhost.ru/54h
https://www.facebook.com/theministryofsolutions/photos/a.139425449561111/971158249721156/ https://www.youtube.com/watch?v=TEyI0eSej2U
https://24gadget.ru/1161070370-razbiraem-huawei-p40-lite-chto-interesnogo-sprjatali-vnutri-video.html
https://www.youtube.com/watch?v=4wym6TjvApg
https://www.techinsights.com/sites/default/files/2019-11/Huawei-Mate-30_board-1.jpg
http://gsmheart.com/remove-huawei-id-mate-30-pro/
https://www.youtube.com/watch?v=imWoHbDuyKE
Comments
7 comments
Huawei Y7 Prime 2018 Test Point
Hi Yana,
Do we need to hold down the TP and GND the entire time or just until the device is detected in Windows.?
Thanks
Paolo
Paolo Bileci
You need to hold them until Passware Kit Mobile shows a "Preparing device" message.
SHaik
Thank you for the link, but this is a Qualcomm based phone, we only support Kirin based Huawei phones at the moment.
Thanks Yana!
This is the Huawei Mate 9 Pro (LON - AL00) TP - tried and tested working!
Dear Paolo,
Thank you for sending the test point image, I have added it here and we will add the device to the database as well!
HUAWEI INE-LX2 ( Nova 3i ) Test Point - KIRIN 710 - Confirmed working.
